5 Ton Wheel Loader
ZT958
Features
International Brand Engine
ZT958 is powered by internationally recognized engine brands, delivering strong and reliable performance for heavy-duty applications. It is designed as a flexible engine platform to meet different emission standards and regional market requirements while maintaining stable working efficiency.
Available engine options include Weichai (standard), Shangchai–CAT technology engine, Cummins (Euro III / EPA Tier 4), Weichai Euro V version, and Fiat 6-cylinder engine (EPA / Euro V dual certification), providing full adaptability for global markets.
Improved Stability & Safer Load Handling Performance
ZT958 delivers improved stability during lifting and loading operations, significantly reducing forward tipping risk and ensuring safer operation under heavy-duty working conditions. The extended wheelbase structure enhances load distribution and ground balance, making the machine more stable during high-load cycles.
Enhanced Lifting Efficiency with Single Boom Structure
The single boom design provides a more rigid structural configuration with fewer stress points, improving lifting force efficiency and ensuring smoother material handling during repeated loading operations. This design enhances overall working efficiency and long-term structural durability.
Optional Climate-Control Cabin for Operator Comfort
Optional heating and cooling air-conditioning system provides a comfortable operating environment in both hot and cold climates, reducing operator fatigue and improving productivity during long working hours.
Floating Bucket Function for Smoother Ground Adaptation
Standard floating bucket function allows the bucket to follow ground contours more smoothly during leveling and loading operations, reducing resistance, improving surface finishing quality, and making operation easier in uneven working conditions.
Extended Dumping Height for Faster Loading Efficiency
ZT958 offers a maximum dump height upgrade up to 3.8 meters, enabling more efficient loading into higher trucks and dumpers. This improves material transfer efficiency, reduces repositioning time, and enhances overall site productivity in loading operations.
Specifications
| Rated Load | kg | 5000 |
| Bucket Width | mm | 3000 |
| Bucket Capacity | m³ | 3 |
| Overall Dimension | mm | 7970*3000*3540 |
| Operating Weight | kg | 17100 |
| Max. Dumping Height | mm | 3400 |
| Max. Dumping Distance | mm | 1200 |
| Wheel Base | mm | 3200 |
| Wheel Tread | mm | 2280 |
| Engine | Weichai/Cummins | |
| Rated Power | kw | 162 |
| Rated Speed | r/min | 2200 |
| Tire Size | 23.5-26 |
