6.5 Ton Crawler Excavator
TCE65
Features
Yanmar Engine with Optional Kubota & Kohler Power Options
Equipped with a Yanmar 4TNV94L engine and optional Kubota or Kohler units, the TCE65 provides flexible global engine solutions with stable output and reliable long-term performance.
Lonking Custom Load-Sensing Hydraulic System for Precise Control
The TCE65 is equipped with a Lonking-custom load-sensing hydraulic system, ensuring precise hydraulic power distribution. It improves digging efficiency, operational smoothness, and fuel utilization under heavy-load working conditions.
Wider Machine Width for Better Stability & Safety
The 1960mm machine width provides a broader stance compared to standard 6.5-ton excavators, improving overall balance and reducing tipping risk. This enhances operational stability and safety, especially during lifting, digging, and uneven terrain work conditions.
Heavy-Duty Steel Tracks for Long Service Life
Standard steel tracks provide strong durability and wear resistance, ensuring reliable performance and longer service life in harsh and demanding job site conditions.
Reinforced Welded Structure for Durability
The machine frame is built with automated welding technology, improving structural strength, weld consistency, and long-term durability under continuous heavy-duty use.
Sound-Insulated Cab with Air Conditioning
The enclosed cab with shock absorption and climate control reduces fatigue and improves operator comfort during long working hours in harsh environments.
Specifications
| Operating Weight | Kg | 6500 |
| Engine Model | Yanmar 4TBV94L | |
| Rated Power | Kw | 36.2 |
| Bucket Capacity | m³ | 0.21 |
| Max Digging Force | Kn | 48 |
| Swing Speed | rpm | 11 |
| Traveling Speed | km/h | 2.5~4.2 |
| Gradeability | ° | 35° |
| Operating Range | ||
| Max.Digging Reach | mm | 5898 |
| Max. Digging Depth | mm | 3860 |
| Max. Digging Height | mm | 5770 |
| Max. Dumping Height | mm | 4075 |
| Min.Swing Radius | mm | 2140 |
| Min.Height at Min.Swing Radius | mm | 4430 |
| Max.Vertical Wall Digging Depth | mm | 3060 |
| Overall Dimensions | ||
| Overall Length | mm | 5550 |
| Overall Width | mm | 1960 |
| Overall Height | mm | 2420 |
| Ground Clearance | mm | 332 |
| Track Length | mm | 2600 |
| Track Gauge | mm | 1560 |
| Track Ground Length | mm | 2020 |
| Swing Radius at Tail | mm | 1520 |
