Name: 16 Ton Compact Bulldozer For Sale with Weichai Engine
Availability: InStock

Features
Specifications
Product Showcase
FAQs
Related Products

Features

Weichai Power System for Heavy Dozing

Equipped with a Weichai WD10G178E25 high-torque diesel engine, the machine delivers strong 131kW output with efficient combustion performance and reliable fuel utilization. Designed for continuous heavy-load dozing applications, it provides stable pushing power under dry, high-resistance soil conditions while maintaining long-term operational durability and low maintenance demand.

Smooth Power Shift Transmission for Efficient Grading Performance

The 3F+3R power shift gearbox combined with planetary torque converter and forced lubrication system ensures smooth power transmission and stable torque delivery. Integrated with hydraulic power-assisted steering, the system significantly reduces operator effort while improving grading efficiency and responsiveness in complex working environments.

High-Pressure Hydraulic System with Overload Protection

The 14MPa working hydraulic system provides stable and consistent pressure output, while the integrated overload protection design effectively reduces wear on hydraulic components. This ensures reliable long-hour performance and minimizes unexpected downtime in demanding earthmoving and land clearing operations.

Heavy-Duty Straight Blade System for Efficient Earthmoving

The 3440×1150mm straight tilt blade delivers strong cutting and pushing capability, enabling efficient soil displacement, site leveling, and large-scale earthmoving operations with improved productivity and reduced cycle time.

Durable Undercarriage System for Dry and Harsh Terrain Conditions

510mm wide track shoes provide strong ground grip and improved load distribution, ensuring stable operation on dry, compacted, and uneven terrain while enhancing overall traction efficiency and machine balance.

Operator Protection Cabin for Enhanced Field Efficiency

The six-sided enclosed cab provides wide visibility and improved operator safety. Combined with an ergonomic control layout, it reduces fatigue and enhances precision during long-duration dozing operations in harsh construction environments.

Integrated Rear Towing System for Multi-Function Capability

Standard rear towing frame allows the machine to support auxiliary operations such as recovery, hauling assistance, and multi-equipment coordination, increasing overall jobsite versatility and operational value.

Specifications

Dimension (L×W×H)	mm	4990 × 3440 × 3110
Operating Weight	t	16
Engine Model	—	WP10G178E355 / WD10G178E25
Rated Power	kW/rpm	131 / 1850
Minimum Fuel Consumption	g/kW·h	214
Ground Contact Length	mm	2430
Ground Pressure	MPa	0.066
Minimum Ground Clearance	mm	405
Gradeability	°	30
Track Shoes (Each Side)	pcs	37
Track Shoe Width	mm	510 (optional: 560 / 610)
Track Gauge	mm	1880
Pitch	mm	203.2
Carrier Rollers (Each Side)	pcs	2
Track Rollers (Each Side)	pcs	6
Maximum Traction Force	kN	144
Blade Type	—	Straight-tilt Blade
Blade Size (L×H)	mm	3440 × 1150
Blade Capacity	m³	4.5
Blade Lift Height	mm	1095
Blade Digging Depth	mm	540
Max Blade Tilt / Inclination	mm	400
Coolant Capacity	L	79
Fuel Tank Capacity	L	300
Engine Oil Capacity	L	19
Forward Speed	km/h	F1:0 ～ 3.29
		F2:0 ～ 5.82
		F3:0 ～ 9.63
Reverse Speed	km/h	R1:0 ～ 4.28
		R2:0 ～ 7.59
		R3:0 ～ 12.53

Product Showcase

Why Choose TDER?

20+ Years of Expertise

158 Countries Served

42,000㎡ of Advanced Production

Over $91M+ Annual Sales

FAQs

Are you a manufacturer or trading company?

TDER is a China-based manufacturer with over 20 years of experience in machinery production and export. Our machines have been exported to 158 countries. We have our own factory covering 42,000 m², integrating R&D, manufacturing, and global sales.

What payment terms do you accept?

We support T/T, L/C, and O/A. Usually, a 30% deposit is required, and the remaining 70% balance should be paid before delivery.

I am a first-time importer and don’t know the import process. What should I do?

We provide full guidance for the import process, from documentation to customs clearance, to ensure a smooth transaction.

What is the delivery time?

Normally, it takes 15–30 days to ship after receiving your deposit. Standard products in stock can be shipped immediately, while customized products may require longer, depending on your order requirements.

What about warranty?

Generally, we offer a 12-month or 2,000 working hours warranty, whichever comes first. Some products may have longer or shorter warranty periods, so please confirm with our sales team before placing your order.

Do you supply spare parts?

Customers can purchase consumable parts together with the machine. For any future replacement, we provide genuine parts at cost price. Parts will be shipped via international express, usually arriving within 7–10 days.

Do you have international certifications?

All our products have CE certification and meet international standards. If you require additional certifications, please consult with our sales team for detailed information.

Can the machine be customized?

Yes, we support OEM/ODM customization including engine brand, color, attachments, and specifications etc.
